Brand Name : Sunswell
Model Number : Depend on capacity
Certification : CE,ISO,SGS
Place of Origin : China
MOQ : 1 Unit
Price : USD 15000 per unit
Payment Terms : L/C, T/T
Supply Ability : 100 units per year
Delivery Time : 45 days
Packaging Details : Standard export wooden case
Automatic grade : Automatic
Driven type : Electric
Voltage : 220V/380V
Application : Beverage
Function : Washing/filling/capping
Type : Filling Machine
Filling material : Juice/Tea/Milk etc.
Material : Stainless Steel,SUS304/SUS 316L
Capacity : 2000-30000bph
Packaging type : Bottles,Cans
Warranty : 12 Months
After-sales service provided : Engineers available to service machinery overseas,Video technical support,Online support,Field installation
Advanced Technology Juice Filling Machine Rotary Washer Filler Capper 3 In 1 Monoblock
Products Description:
The machine is mainly used for washing/filling/capping PET bottle juice, tea drinks and all kinds of energy drink for hot filling. Only need to change a few spare parts, that can suitable for filling pure water and mineral water.
Application :
Fruit juice, NFC juice,energy drinks, ice tea drinks, coffee beverage,pulp juice , flavored milk , sports beverage drink,ginger
drink , flavored water drinks. Apple juice ,Orange juice, cherry juice, mango juice ,tomato juice, pineapple juice, guava
juice,passion fruit drinks ,papaya juice.
Detailed Image: Equipment structure:
1. Rinsing system: Combined with rotary tray with clamp, water distributing tray, water tank and rinsing
pump.
2. Filling system: Combined with hydraulic, filling valve, controlling ring, and elevator-cylinder.
3. Capping system: Combined with capper, cap sorter and cap falling track.
4. Driving system: Combined with main motor and gears.
5. Bottle transmitting system: Combined with air conveyor, steel starwheels and neck supporting carrier plates.
6. Electrical controlling system: this part is frequency inverted, PLC controlled and touch screen operated.
------------------------Bottle infeed----------------------------------Discharge Starwheel--------------------
-----------------------------------Rinser---------------------------------------------------------------------Filler-----------------------
--------------------------------Capper-----------------------------------------------------------------Capper-------------------------------
Main components configuration:
1. Material of filling valve: Stainless steel 316L available
2. Material of rotary tray and machine platform of rinser and filler: Stainless steel 304.
3. Main motor: ABB/SEW (Germany)
4. Sliding bearing: Igus (Germany)
5. Frequency inverter: MITSUBISHI (Japan)
6. Touch screen: DIGITAL (Japan).
7. PLC: MITSUBISH (Japan)
8. Pneumatic components: FESTO (Germany)
9. Seals: Busak+Shamban (USA)
10. Photocell switch: BANER (USA).
11. Proximity switch: TURCK (Germany).
![]() |
