CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging

Name: CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging
Brand: Sunwell
Price: 1 USD

CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging Manufactures

Brand Name : Sunwell

Model Number : SUNSWELL

Certification : CE,SGS,ISO

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, T/T

Supply Ability : 100sets per year

Delivery Time : 45days

Packaging Details : Standard export wooden case

Processing types : Gravity Pressure Filling,Mineral water or pure water,Automatic Bottle Filling Sealing Machine,Spring Water

Automatic grade : Automatic

Driven type : Electric,Pneumatic

Voltage : Can be designed

Material : Stainless Steel 304/316

Filling material : Mineral water,pure water,Pure/Mineral water

After-sales service provided : Engineers available to service machinery overseas,Online support,Video technical support,Field installation,Free spare parts

Warranty : 12 Months

Contact Now

Automatic 5 Gallon Mineral Drink Water Barrel Filling Packaging Machine

Product Description of 5 gallon filling and packing machine:
5 gallon water filling production line to introduce US companies production technology and crafts, the integration of Italy, France and other countries the advantages of similar products. The technical improvement of the automatic filling machine production line, advanced equipment technology, reliable performance, process science, good food hygiene conditions, high degree of production automation and easy to operate.
The machine body all use high quality stainless steel material, other parts are also non-toxic, durable combination of materials, electrical, pneumatic system using imported components, so the equipment failure rate is low, high reliability.

Complete Line Flow of 18.9L washer filler capper:
ChartEmpty bottle Conveyor belt---→Caps Decapper---→ Brush External Bottle Washer ---→Automatic Bottle Loading System---→Internal Bottle Washer/ Disinfecter ---→ Rotary Filler ---→ Chain Plate Capper with caps washer---→Filled Bottle Conveyor Belt---→Lamp Checker---→Insert the caps label Sleeve Labeling Machine---→Heat Shrinking Machine---→Chain Style Bottle Lifter ( for the purpose to put on the plastic film cover) ---→Filled Bottles Conveyor Belt to the truck or stock room.

Basic Specification of 5 gallon brewing and making machine:

Model	WFC Series
Applicable Container	3 gallon ,5 gallon bottle
The capacity of this machine is range from 100BPH to 2000BPH .
Customized service includes automatic cap fuller, internal and external barrel scrubber, cap elevator and heat shrinker, etc.

Technical Parameter of 20L water production line:

Model	WFC-100	WFC-200	WFC-300	WFC-450	WFC-600	WFC-900	WFC-1200	WFC-1500
Rated Production(BPH)	100	200	300	450	600	900	1200	1500
Installed capacity	1.3	1.7	3.8	3.8	7.5	9.7	13.5	16.5
Weight(kg)	680	800	1500	2100	3000	3500	4500	5500

Main Features of purified water rinsing filling capping machine:
1.Machine set rinsing, filling, capping function in one.
2.The overall use of high-quality stainless steel, corrosion-resistant, easy to clean.
3.The main electrical components and the original airway are imported brands.
4.Pump selection of Hangzhou South pump products (optional Grundfos).
5.The nozzle is made with American spray technology.

CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging

More information pls contact :
Sam
+86 138 1284 5656
www.sunswell.com
Zhangjiagang Sunswell Machinery Co., Ltd
